Euroimmun Analyzer I

ELISA Automation for Medium to High Throughput Testing Facilities

The EUROIMMUN Analyzer I is a fully automated ELISA system that can handle up to 7 microplates and 180 patient samples in one run. It is an open system that can process all EUROIMMUN ELISA tests, making it ideal for medium- to high-throughput ELISA automation. The EUROIMMUN Analyzer I ensures accuracy and reliability by automatically recognizing and assigning reagents and importing QC data using Data Matrix codes. It also offers fast and convenient operation, with a software interface that allows the scanning of QC certificates using a 2D hand barcode scanner. It can perform up to 70 tests per hour, delivering quick and reliable results.

×

Request a Quote


Fully Automated ELISA Processor

Everlife Euroimmun Analyzer provides fully automated operation, handling up to 7 plates and 180 samples per run, ensuring optimal speed, accuracy, and traceability.

Advantages of the ELISA Analyzer:

  • Fully automated ELISA processor that can handle up to 7 microplates and 180 patient samples in one run.
  • Open system that can process all EUROIMMUN ELISA tests.
  • A user-friendly software interface that allows scanning of QC certificates using a 2D-hand barcode scanner.

Benefits of Euroimmun Analyzer I:

  • Increased efficiency and productivity for medium- to high-throughput laboratories.
  • A versatile solution for autoimmune and infection diagnostics.
  • The automatic recognition and assignment of reagents and the import of QC data using Data Matrix codes ensure accuracy and reliability.
  • Up to 70 tests per hour deliver quick and reliable results.
  • An optional climate control unit ensures constant incubation conditions.

Features of ELISA Processor:

  • Fully automated ELISA processing for medium to high sample volume with minimal manual input
  • Open system with over 800 validated parameters available for autoimmune and infection diagnostics
  • High-speed processing of up to 70 tests per hour and up to 7 plates and 180 samples per run
  • High convenience through the use of barcode identification.
  • Convenient operation of the software including scanning of QC certificates using a 2D-hand barcode scanner

Technical Specification


   Sample types Plasma, serum, CSF and stool
   Patient sample capacity up to 180 samples
   Plate capacity up to 7
   Parameter capacity per run up to 54
   Shakeable incubators 4
   Throughput up to 70 tests per hour
   Sample tubes Outer diameter 10 – 16 mm, height up to 100 mm
   Traceability integrated code scanner for identification of samples and reagents
   User interface Microsoft ® Windows ® 10 Enterprise 2019 LTSC (64 Bit)
   Online connection ASTM interface, bi-directional
   Dimensions (WxDxH) 1100 mm x 750 mm x 1000 mm
   Weight 130 kg
